DLA408A
fdB
8518220000
Description:
DLA408A is an active line array speaker with two channnels digital amplifier with DSP.Three-point connection way makes the hanging,supporting and stacking more fast,stable and safe.The system has the characteristics of light weight and good compatibility.The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●Product parameters have been entered into EASE loudspeaker database
●Mid-high coaxial unit, real 3-way speaker, clear and bright
●Active way, simple operation, save amplifiers
●Quick setup for hanging and stacking.
●Applications: multifunction halls, lecture halls, auditoriums, stadiums and touring
Specification:
| MODEL | DLA408A |
| FREQUENCY RESPONSE(-3dB) | 80Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 75Hz-20kHz |
| LF DRIVERS | 2×8"Neo/2"voice coil |
| MF DRIVERS | 1×1.4"Neo/3.5"voice coil |
| HF DRIVERS | 1×1.4"Neo/1.7"voice coil |
| RATED POWER | 300W/8Ω+600W/8Ω |
| SENSITIVITY(1watt/1meter) | -- |
| MAXIMUM SPL | 125dB continuous,131dB peak |
| NOMINAL IMPEDANCE | -- |
| DISPERSION(-6dB) | Horizontal : 100° |
| CROSSOVER FREQUENCIES | -- |
| INPUT CONNECTORS | XLR |
| PACKAGE SIZE | 605×392×655mm |
| NET WEIGHT | 23 kg/pc |
| GROSS WEIGHT | 26 kg/pc |
Configuration:
Data Sheets Download:
