| Quantity: | |
|---|---|
DLA310
fdB
8518220000
Description:
DLA310 is a dual 10'',2-way line array speaker,DLA410 is a dual 10'',3-way line array speaker,DLA118W is a single 18'' subwoofer,can be combined with DLA410 to be a line array system.DLA410A is an active line array speaker with two channels digital amplifier with DSP,DLA118WA is an active subwoofer with digital amplifier with DSP,The two models are combined into an active line array sound reinforcement system.Three-point connection way makes the hanging,supporting and stacking more fast,stable and safe.The system has the characteristics of light weight and good compatibility.The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●Product parameters have been entered into EASE loudspeaker database
●Mid-high coaxial unit, real 3-way speaker, clear and bright
●Passive way for full range speaker, simple operation
●Accurate coverage angle and uniform change with frequency
●Subwoofer with bass-reflex design,full and powerful sound
●Aluminum driver mounting plate,aluminum waveguide,greatly reduce the power compression
●Multiple ways of combination use
●Applications:Theaters,concert halls,multifunction halls, large auditoriums, stadiums and touring
Specification:
| MODEL | DLA310 |
| FREQUENCY RESPONSE(-3dB) | 60Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 55Hz-20kHz |
| LF DRIVERS | 2×10"Neo/3"voice coil |
| MF DRIVERS | -- |
| HF DRIVERS | 1×1.4"Neo/3"voice coil |
| RATED POWER | 500W RMS 2000W peak |
| SENSITIVITY(1watt/1meter) | 101dB |
| MAXIMUM SPL | 127dB continuous,133dB peak |
| NOMINAL IMPEDANCE | 8 ohms |
| DISPERSION(-6dB) | Horizontal : 90° |
| CROSSOVER FREQUENCIES | 900Hz |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKAGE SIZE | 537×400×720mm |
| NET WEIGHT | 25 kg/pc |
| GROSS WEIGHT | 29 kg/pc |
Configuration:
