| Quantity: | |
|---|---|
DLA118W
fdB
8518210000
Description:
DLA118W is a single 18" subwoofer. It features 1x18" 100mm voice coil woofer, bass-reflex design, three-point hanging system matched with DLA410, can be hung and stacked to improve the low frequency performance of the system. The cabinet is made of multilayer composite plywood with wearresistant polyurea paint. DLA118WA is an active subwoofer with one channel digital amplifier with DSP to match with DLA410A.
Features:
●High quality component, bass-reflex design, full and powerful sound
●Quick setup for hanging and stacking
●Applications: theaters, concert halls, multifunction halls, lecture halls, auditoriums, stadiums, live houses, and touring
Specification:
| MODEL | DLA118W |
| FREQUENCY RESPONSE(-3dB) | 45Hz-250kHz |
| FREQUENCY RESPONSE(-10dB) | 40Hz-300kHz |
| LF DRIVERS | 1×18"/4"voice coil |
| MF DRIVERS | -- |
| HF DRIVERS | -- |
| RATED POWER | 600W RMS 2400W peak |
| SENSITIVITY(1watt/1meter) | 99dB |
| MAXIMUM SPL | 127dB continuous,133dB peak |
| NOMINAL IMPEDANCE | 8 ohms |
| DISPERSION(-6dB) | -- |
| CROSSOVER FREQUENCIES | -- |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKAGE SIZE | 772×715×615mm |
| NET WEIGHT | 45 kg/pc |
| GROSS WEIGHT | 51 kg/pc |
Data Sheets Download:
