DLA118WA
fdB
8518210000
Description:
DLA118WA is an active subwoofer with digital amplifier with DS.Three-point hanging system matched with DLA410A, can be hung and stacked to improve the low frequency performance of the system. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●High quality component, bass-reflex design, full and powerful sound
●Quick setup for hanging and stacking
●Applications: theaters, concert halls, multifunction halls, lecture halls, auditoriums, stadiums, live houses, and touring
Specification:
| MODEL | DLA118WA |
| FREQUENCY RESPONSE(-3dB) | 45Hz-250kHz |
| FREQUENCY RESPONSE(-10dB) | 40Hz-300kHz |
| LF DRIVERS | 1×18"/4"voice coil |
| MF DRIVERS | -- |
| HF DRIVERS | -- |
| RATED POWER | 1300W/8Ω |
| SENSITIVITY(1watt/1meter) | -- |
| MAXIMUM SPL | 127dB continuous,133dB peak |
| NOMINAL IMPEDANCE | -- |
| DISPERSION(-6dB) | -- |
| CROSSOVER FREQUENCIES | -- |
| INPUT CONNECTORS | XLR |
| PACKAGE SIZE | 772×715×615mm |
| NET WEIGHT | 47 kg/pc |
| GROSS WEIGHT | 53 kg/pc |
Configuration:
