DLA408
fdB
8518220000
Description:
DLA408 is a dual 8'',3-way line array speaker can be combined with the subwoofer to be a line array system.Three-point connection way makes the hanging,supporting and stacking more fast,stable and safe.The system has the characteristics of light weight and good compatibility.The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●Product parameters have been entered into EASE loudspeaker database
●Mid-high coaxial unit, real 3-way speaker, clear and bright
●Passive way, simple operation, save amplifiers
●Quick setup for hanging and stacking.
●Applications: multifunction halls, lecture halls, auditoriums, stadiums and touring
Specification:
| MODEL | DLA408 |
| FREQUENCY RESPONSE(-3dB) | 80Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 75Hz-20kHz |
| LF DRIVERS | 2×8"Neo/2"voice coil |
| MF DRIVERS | 1×1.4"Neo/3.5"voice coil |
| HF DRIVERS | 1×1.4"Neo/1.7"voice coil |
| RATED POWER | 400W RMS,1600W peak |
| SENSITIVITY(1watt/1meter) | 99dB |
| MAXIMUM SPL | 125dB continuous,131dB peak |
| NOMINAL IMPEDANCE | 8 ohms |
| DISPERSION(-6dB) | Horizontal : 100° |
| CROSSOVER FREQUENCIES | 900Hz,6KHz |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKAGE SIZE | 515×375×655mm |
| NET WEIGHT | 21 kg/pc |
| GROSS WEIGHT | 24 kg/pc |
Configuration:
