K15B
fdB
8518210000
Description:
K series is a group of two-way column system with two channels digital amplifier with DSP. The small-sized column uses aluminum alloy housing and neodymium units,with small size, light weigh,high sensitivity,clear and bright sound,can be used alone or combined with active subwoofers into a sound reinforcement system. K12BAS, K15BAS are active subwoofers with two channels digital amplifier with DSP.
Features:
●Small volume and light weight for full range speaker
●Clear and bright sound for full range
●Full function, rich and elastic bass
●Multiple ways of instllation and combination
●Applications: band performance, small mobile business performance,conference rooms,multi-purpose halls, churches
Specification:
MODEL | K15B |
| FREQUENCY RESPONSE(-3dB) | 45Hz-250Hz |
FREQUENCY RESPONSE(-10dB) | 40Hz-300Hz |
LF DRIVERS | 1x15"/3"voice coil |
| HF DRIVERS | -- |
RATED POWER | 400W RMS,1600W peak |
SENSITIVITY(1watt/1meter) | 99dB |
MAXIMUM SPL | 125dB continuous,131dB peak |
IMPEDANCE | 8ohms |
DISPERSION(-6dB) | -- |
| CROSSOVER FREQUENCIES | -- |
INPUT CONNECTORS | 2×Speakon NL4 |
PACKAGE SIZE | 742x497x698mm |
NET WEIGHT | 32 kg/pc |
GROSS WEIGHT | 36 kg/pc |
Data Sheets Download:
