| Quantity: | |
|---|---|
K12BAS
fdB
8518210000
Description:
K series is a group of two-way column system with two channels digital amplifier with DSP. The small-sized column uses aluminum alloy housing and neodymium units,with small size, light weigh,high sensitivity,clear and bright sound,can be used alone or combined with active subwoofers into a sound reinforcement system. K12BAS, K15BAS are active subwoofers with two channels digital amplifier with DSP.
Features:
●Small volume and light weight for full range speaker
●Clear and bright sound for full range
●Full function, rich and elastic bass
●Multiple ways of instllation and combination
●Applications: band performance, small mobile business performance,conference rooms,multi-purpose halls, churches
Specification:
MODEL | K12BAS |
| FREQUENCY RESPONSE(-3dB) | LF:45Hz-250Hz,System,45Hz-18kHz |
FREQUENCY RESPONSE(-10dB) | LF:40Hz-300Hz,System,40Hz-20kHz |
LF DRIVERS | 1x12"/3"voice coil |
| HF DRIVERS | -- |
RATED POWER | 1500W/8Ω+460W/8Ω |
SENSITIVITY(1watt/1meter) | -- |
MAXIMUM SPL | 121dB continuous,127dB peak |
IMPEDANCE | -- |
DISPERSION(-6dB) | -- |
| CROSSOVER FREQUENCIES | -- |
INPUT CONNECTORS | XLR |
PACKAGE SIZE | 605x415x632mm |
NET WEIGHT | 26 kg/pc |
GROSS WEIGHT | 30 kg/pc |
Data Sheets Download:
