S215
fdB
8518220000
Description:
The S215 is a dual 15" two way full range speaker with bright and powerful sound. Unit configuration: 2x15" high efficiency mid-bass unit, 1x2" exit throat 75mm titanium diaphragm HF driver with 90°×50° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●High quality unit configuration, high SPL
●Rotatable horn, multi-ways for installation
●Applications: conference rooms, multifunction halls, classrooms , hotel entertainment, touring
Specification:
MODEL | S215 |
FREQUENCY RESPONSE(-3dB) | 50Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 45Hz-20KHz |
LF DRIVERS | 2×15"/3"voice coil |
| HF DRIVERS | 1×2"/3"voice coil |
RATED POWER | 800W RMS,3200W peak |
SENSITIVITY(1watt/1 metre) | 99dB |
MAXIMUM SPL | 128dB continuous,134 dB peak |
IMPEDANCE | 4 ohms |
DISPERSION(-6dB) | 80°X40° |
CROSSOVER FREQUENCIES | 1.3kHz |
INPUT CONNECTORS | 2×Speakon NL4 |
PACKAGE SIZE | 715×615×1255mm |
NET WEIGHT | 55 kg/pc |
GROSS WEIGHT | 61 kg/pc |
Configuration:
