| Quantity: | |
|---|---|
S110
fdB
8518220000
Description:
The S110 is a 10", small sized, two way full range speaker with clear and soft sound. Unit configuration: 1x10" high efficiency mid-bass unit, 1x1" exit throat 44mm poliyimide diaphragm HF driver with 90°×50° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●High quality units,high strength plywood
●Multi-hanging points and support,easy and quick operation
●Complete models
●Applications:conference rooms,multi-purpose halls,various entertainment venues,mobile performances
Specification:
MODEL | S110 |
FREQUENCY RESPONSE(-3dB) | 70Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 65Hz-20KHz |
LF DRIVERS | 1×10"/2.5"voice coil |
| HF DRIVERS | 1×1"/1.7"voice coil |
RATED POWER | 250W RMS,1000W peak |
SENSITIVITY(1watt/1 metre) | 95dB |
MAXIMUM SPL | 119dB continuous,125 dB peak |
IMPEDANCE | 8 ohms |
DISPERSION(-6dB) | 90°X50° |
CROSSOVER FREQUENCIES | 1.7kHz |
INPUT CONNECTORS | 2×Speakon NL4 |
PACKAGE SIZE | 395×395×575mm |
NET WEIGHT | 14 kg/pc |
GROSS WEIGHT | 17 kg/pc |
Configuration:
Data Sheets Download:
