| Quantity: | |
|---|---|
S106
fdB
8518220000
Description:
The S106 is a 6.5" 2-way full range speaker,it uses 1x6.5" high effiency mid-bass unit,1x1" exit throat 2mm voice coil HF drive with 90°x50° rotatabla horn. The wood box adopts multlaye composite plywoof with special enviromental protection paint.
Features:
●High quality units,high strength plywood
●Multi-hanging points and support,easy and quick operation
●Complete models
●Applications:conference rooms,multi-purpose halls,various entertainment venues,mobile performances
Specification:
MODEL | S106 |
FREQUENCY RESPONSE(-3dB) | 90Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 85Hz-20KHz |
LF DRIVERS | 1×6.5"/2"voice coil |
| HF DRIVERS | 1×1"/1"voice coil |
RATED POWER | 120W RMS,480W peak |
SENSITIVITY(1watt/1 metre) | 90dB |
MAXIMUM SPL | 111dB continuous,117 dB peak |
IMPEDANCE | 8 ohms |
DISPERSION(-6dB) | 110°X50° |
CROSSOVER FREQUENCIES | 2.5kHz |
INPUT CONNECTORS | Covered barrier strip terminals |
PACKAGE SIZE | 530×280×450mm(1 Pair) |
NET WEIGHT | 7 kg/pc |
GROSS WEIGHT | 16 kg/pair |
Configuration:
Data Sheets Download:
