S206
fdB
8518220000
Description:
The S206 is a 2x6.5", small sized, light weight, two way full range speaker with clear and soft sound. Unit configuration: 2x6.5" high efficiency mid-bass unit, 1x1" exit throat 34mm polyester diaphragm HF driver coaxial unit. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●Clear and soft sound
●High quality units,high strength plywood
●Multi-hanging points and support,easy and quick operation
●Complete models
●Applications:conference rooms,multi-purpose halls,various entertainment venues,mobile performances
Specification:
MODEL | S206 |
FREQUENCY RESPONSE(-3dB) | 90Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 85Hz-20KHz |
LF DRIVERS | 2×6.5"/2"voice coil |
| HF DRIVERS | 1×1"/1.4"voice coil |
RATED POWER | 240W RMS,960W peak |
SENSITIVITY(1watt/1 metre) | 93dB |
MAXIMUM SPL | 116dB continuous,122 dB peak |
IMPEDANCE | 4 ohms |
DISPERSION(-6dB) | 90°X50° |
CROSSOVER FREQUENCIES | 300Hz,2.5kHz |
INPUT CONNECTORS | Covered barrier strip terminals |
PACKAGE SIZE | 280×280×490mm |
NET WEIGHT | 10 kg/pc |
GROSS WEIGHT | 12 kg/pc |
Configuration:
