S112
fdB
8518220000
Description:
The S112 is a 12" two way full range speaker with clear,soft and powerful sound. Unit configuration: 1x12" high efficiency mid-bass unit, 1x1" exit throat 44mm polyester diaphragm HF driver with 90°×50° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●High quality unit configuration, high SPL
●Rotatable horn, multi-ways for installation
●Applications: conference rooms, multifunction halls, classrooms , hotel entertainment, touring
Specification:
MODEL | S112 |
FREQUENCY RESPONSE(-3dB) | 55Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 50Hz-20KHz |
LF DRIVERS | 1×12"/3"voice coil |
| HF DRIVERS | 1×1"/1.7"voice coil |
RATED POWER | 300W RMS,1200W peak |
SENSITIVITY(1watt/1 metre) | 97dB |
MAXIMUM SPL | 122dB continuous,128 dB peak |
IMPEDANCE | 8 ohms |
DISPERSION(-6dB) | 90°X50° |
CROSSOVER FREQUENCIES | 1.7kHz |
INPUT CONNECTORS | 2×Speakon NL4 |
PACKAGE SIZE | 470×470×715mm |
NET WEIGHT | 20 kg/pc |
GROSS WEIGHT | 24 kg/pc |
Configuration:
