LT215
fdB
8518220000
Description:
The LT215 is a compact, 15" coaxial-driver, 2-way,highly weather-resistant full range loudspeaker with high SPL, The product design gives priority to waterproof,dustproof,winproof and anti-UV aging,the unit is specially made and treated,the cabinet is formed by engineering plastic mold with five-layer of different materials composite grille.The product meets the IP56 standard(the fixed angle between front face and horizontal plane≤90°),the exposed metal parts are sprayed with stainless steel or aluminum,and the mounting bracket is sprayed with low-carbon steel to meet the all-weather use.The version can be customized to adapt to the marine environment(the mounting bracket is upgraded to 316 stainless steel).The audio transformer and band switch are designed to achieve a variety of different output powers including constant resistance.
Features:
●Highly weather-resistant IP56 rating
● Engineering plastic injection molding
● High SPL
● Horn loaded design for coaxial components
●Five-layer of different materials composite geille
●Stainless steel or aluminium rigging parts
●Multiple models to meet outdoor sound reinforcement
● Good used for sports facilities, stadiums,water parks,outdoor background music,swimming pools and a wide variety of other outdoor venue types.
Specification:
| MODEL | LT215 |
| FREQUENCY RESPONSE(-3dB) | 50Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 45Hz-20kHz |
| LF DRIVER | 1×15''/3''voice coil |
| HF DRIVER | 1×1.4''/3''voice coil |
| INPUT VOLTAGE | -- |
| RATED POWER | 400W RMS,1600W peak |
| SENSITIVITY(1watt/1meter) | 103dB |
| MAXIMUM SPL | 129dB continuous,135dB peak |
| IMPEDANCE | 8ohms |
| DISPERSION(-6dB) | 60°×40° |
| CROSSOVER FREQUENCIES | 1.5kHz |
| INPUT CONNECTORS | covered barrier strip terminals |
| PACKAGE SIZE | 610×585×570mm |
| NET WEIGHT | 28.5kg/pc |
| GROSS WEIGHT | 31.5kg/pc |
Configuration:
