LT206T
fdB
8518220000
Description:
LT206T is a 6.5",coaxial, two-way, all-weather speaker, with waterproof, dustproof, windproof, anti-uv aging, specially designed dustproof and waterproof cover for input and output, has a pressing device, multi-layer different functional grille. The cabinet meets the IP56 standard. The exposed metal parts are made of stainless steel or aluminum, and the mounting bracket is sprayed with low-carbon steel, which can meet allweather use (the version suitable for the marine environment can be customized, and the mounting bracket is upgraded to 316 stainless steel). Unit configuration: 1x6.5" ferrite mid-bass and 1x 0.8" exit throat 25mm HF driver coaxial unit, the cabinet is made of polymer compound injection molding. LT206T is equipped with transformer and band switch based on LT206 to achieve a variety of different output powers including constant resistance.
Features:
●Pass IP56 testing, meet all-weather use
●The cabinet is made of polymer compound injection molding
● Coaxial point sound source
● Applications: outdoor restaurants, bars, parks, near-filed sound reinforcement of scenic areas, houseboats and seasides (customized)
● Customized unit, better bass performance
Specification:
| MODEL | LT206T |
| FREQUENCY RESPONSE(-3dB) | 105Hz-17kHz |
| FREQUENCY RESPONSE(-10dB) | 100Hz-18kHz |
| LF DRIVER | 1×6.5''/1.4''voice coil |
| HF DRIVER | 1×0.8''/1''voice coil |
| INPUT VOLTAGE | 100V |
| RATED POWER | 25W/ 50W/100W/OFF/,8Ω 100W |
| SENSITIVITY(1watt/1meter) | 93dB |
| MAXIMUM SPL | 113dB continuous,119dB peak |
| IMPEDANCE | 8ohms |
| DISPERSION(-6dB) | 100°×100° |
| CROSSOVER FREQUENCIES | 2.8kHz |
| INPUT CONNECTORS | covered barrier strip terminals |
| PACKAGE SIZE | 323×323×293mm |
| NET WEIGHT | 7kg/pc |
| GROSS WEIGHT | 8.5kg/pc |
Configuration:
Data Sheets Download:
