LT212T
fdB
8518220000
Description:
The LT212T is a compact, 12" coaxial-driver, 2-way,highly weather-resistant full range loudspeaker with high SPL, the body is made of engineering plastic injection molding. The system conforms to IP56 international standard.LT212T is equipped with multi-tap transformer based on LT212.
Features:
●Product parameters have been entered into EASE loudspeaker database
●Pass IP56 testing, meet all-weather use
●The cabinet is made of polymer compound injection molding
●Coaxial point sound source
●Horn-loaded design
●Applications: outdoor restaurants, bars, parks, plazas, stadiums, sound reinforcement of scenic areas, transportation hubs, houseboats, seasides (customized)
Specification:
MODEL | LT212T |
| FREQUENCY RESPONSE(-3dB) | 55Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 50Hz-20kHz |
| LF DRIVER | 1×12''/3''voice coil |
| HF DRIVER | 1×1''/1.7''voice coil |
| INPUT VOLTAGE | 100V |
| RATED POWER | 50W/100W/200W/OFF/8Ω300W |
| SENSITIVITY(1watt/1meter) | 98dB |
| MAXIMUM SPL | 123dB continuous,129dB peak |
| IMPEDANCE | 8ohms |
| DISPERSION(-6dB) | 70°×50° |
| CROSSOVER FREQUENCIES | 2.2kHz |
| INPUT CONNECTORS | covered barrier strip terminals |
| PACKAGE SIZE | 472×442×460mm |
| NET WEIGHT | 20kg/pc |
| GROSS WEIGHT | 22kg/pc |
Configuration:
