PS112/PS112A
fdB
8518220000
Description:
The PS112/PS112A series is a 12''two-way full-range londspeaker system,strong polypropylene material box of professional speakers,with the characteristics of full functions,light weight,high SPL,clear,bright and balanced sound quality,exquisite appearance and so on.All adopt high quality unit configuration, the box molded by injection mold.
Features:
● Strong polypropylene box,injection molding
● High quality unit configuration
● Digital amplifier with DSP,multiple preset modes can be selected or stored
● Multiple hanging points and support,easy to use
●Applications: Conference rooms,Multi-function halls,Entertainment venues,Mobile Performances
Specification:
| MODEL | PS112 | PS112A |
| FREQUENCY RESPONSE(-3db) | 65Hz-18kHz | 65Hz-18kHz |
| FREQUENCY RESPONSE(-10db) | 60Hz-20KHz | 60Hz-20KHz |
| LF DRIVER | 1×12",2.5''voice coil | 1×12",2.5''voice coil |
| HF DRIVER | 1×1",1.4''voice coil | 1×1",1.4''voice coil |
| RATED POWER | 250W RMS 1000W peak | 400W/8Ω+100W/8Ω |
| SENSITIVITY(1watt/1meter) | 97dB 1 | -- |
| MAXIMUM SPL | 120dB continuous 126dB peak | 120dB continuous 126dB peak |
| IMPEDANCE | 8 ohms | -- |
| DISPERSION(-6dB) | 90°×60° | 90°×60° |
| CROSSOVER FREQUENCIES | 1.9kHz | -- |
| INPUT CONNECTORS | 2×Speakon NL4 | XLR |
| PACKAGE SIZE(1Pair) | 450×450×685mm | 450×450×685mm |
| NET WEIGHT | 18kg/pc | 20kg/pc |
| GROSS WEIGHT | 21kg/pc | 23kg/PC |
Configuration:
