| Quantity: | |
|---|---|
PS115/PS115A
fdB
8518220000
Description:
The PS115/PS115A series is a 10''two-way full-range londspeaker system,strong polypropylene material box of professional speakers,with the characteristics of full functions,light weight,high SPL,clear,bright and balanced sound quality,exquisite appearance and so on.All adopt high quality unit configuration, the box molded by injection mold.
Features:
● Strong polypropylene box,injection molding
● High quality unit configuration
● Digital amplifier with DSP,multiple preset modes can be selected or stored
● Multiple hanging points and support,easy to use
●Applications: Conference rooms,Multi-function halls,Entertainment venues,Mobile Performances
Specification:
| MODEL | PS115 | PS115A |
| FREQUENCY RESPONSE(-3db) | 65Hz-18kHz | 65Hz-18kHz |
| FREQUENCY RESPONSE(-10db) | 55Hz-20KHz | 55Hz-20KHz |
| LF DRIVER | 1×15",2.5''voice coil | 1×15",2.5''voice coil |
| HF DRIVER | 1×1",1.4''voice coil | 1×1",1.4''voice coil |
| RATED POWER | 300W RMS 1200W peak | 400W/8Ω+100W/8Ω |
| SENSITIVITY(1watt/1meter) | 98dB | -- |
| MAXIMUM SPL | 122dB continuous 128dB peak | 122dB continuous 128dB peak |
| IMPEDANCE | 8 ohms | -- |
| DISPERSION(-6dB) | 90°×60° | 90°×60° |
| CROSSOVER FREQUENCIES | 2.2kHz | -- |
| INPUT CONNECTORS | 2×Speakon NL4 | XLR |
| PACKAGE SIZE(1Pair) | 500×500×771mm | 500×500×771mm |
| NET WEIGHT | 21kg/pc | 23kg/pc |
| GROSS WEIGHT | 25kg/pc | 27kg/PC |
Configuration:
