| Quantity: | |
|---|---|
U115DA
fdB
8518220000
Description:
The U115DA is a classic professional speaker with the characteristics of high power,high SPL,clear and bright full-ranfe sound,rich and elastic bass,all use high quality units.The cabinet is made of multi-layer composite plywood with wear-resistant polyurea paint.
Features:
●Product parameters have been entered into EASE loudspeaker database
●High quality unit configuration, high strength plywood housing
●Multi-hanging points and support, easy and quick operation
●Applications: large-scale indoor sound reinforcement, multifunction halls, high-end hotel clubs, touring, band reinforcement and monitor speaker
Specification:
MODEL | U115DA |
FREQUENCY RESPONSE(-3dB) | 45Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 40Hz-20KHz |
LF DRIVERS | 1×15"/3"voice coil |
| HF DRIVERS | 1×1"/1.7"voice coil |
RATED POWER | 1500W/8Ω+460W/8Ω |
SENSITIVITY(1watt/1 metre) | -- |
MAXIMUM SPL | 124dB continuous,130 dB peak |
IMPEDANCE | -- |
DISPERSION(-6dB) | 90°x 40° |
CROSSOVER FREQUENCIES | -- |
INPUT CONNECTORS | XLR |
PACKAGE SIZE | 550×524×807mm |
NET WEIGHT | 29 kg/pc |
GROSS WEIGHT | 34 kg/pc |
Configuration:
Data Sheets Download:
