S108
fdB
8518220000
Description:
The S108 is a 8", small sized, light weight, two way full range speaker with clear and soft sound. Unit configuration: 1x8" high efficiency mid-bass unit, 1x1" exit throat 25mm mylar diaphragm HF driver with 90°×50° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint.
Features:
●High quality units,high strength plywood
●Multi-hanging points and support,easy and quick operation
●Complete models
●Applications:conference rooms,multi-purpose halls,various entertainment venues,mobile performances
Specification:
| MODEL | S108 |
| FREQUENCY RESPONSE(-3dB) | 80 Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 75Hz-20KHz |
| LF DRIVERS | 1×8"/2"voice coil |
| HF DRIVERS | 1×1"/1"voice coil |
| RATED POWER | 150W RMS,600W peak |
| SENSITIVITY(1watt/1 metre) | 93dB |
| MAXIMUM SPL | 115dB continuous,121 dB peak |
| IMPEDANCE | 8 ohms |
| DISPERSION(-6dB) | 90°×50° |
| CROSSOVER FREQUENCIES | 2.8kHz |
| INPUT CONNECTORS | Covered barrier strip terminals |
| PACKAGE SIZE | 340×340×518mm |
| NET WEIGHT | 10 kg/pc |
| GROSS WEIGHT | 12 kg/pc |
Configuration:
