IP46 ES106B/ES106W 6'' Waterproof Speaker Cabinet

6'' waterproof speaker cabinet , Engineering plastic injection molding

Availability:

Quantity:



Inquire Add to Basket

Model:
ES106B/ES106W
Brand:
fdB
Code:
8518220000

Product Description

Description:

The ES106B/ES106W is a highly weather-resistant,single 6" 2-way full range loudspeaker, the body is made of engineering plastic injection molding.fitted with one 6" mid-woofer and one 1" HF driver. The system conforms to IP46 international standard.ES106T is equiped with multi-tap transformer based on ES106

Features:

● Highly weather-resistant IP46 rating
● Engineering plastic injection molding
● Two kinds of mounting brackets
● Good used for meeting rooms, shops, water parks,outdoor background music, swimming pools, and a wide variety of other outdoor or indoor backgound music

Specification:

MODEL	ES106B/ES106W
FREQUENCY RESPONSE(-3dB)	60Hz-18KHz
FREQUENCY RESPONSE(-10dB)	55Hz-20KHz
DRIVERS	1×6"(150mm)/1.5"voice coil LF
	1×1"(25mm)/1"voice coil HF
INPUT VOLTAGE
RATED POWER	80W RMS. 320W peak
SENSITIVITY	89dB 1watt/1 metre
MAXIMUM SPL	108dB continuous,114 dB peak
IMPEDANCE	16 ohms nominal
DISPERSION(-6dB)	90°×60°
CROSSOVER FREQUENCIES	2.4kHz passive
INPUT CONNECTORS	covered barrier strip terminals
PACKAGE SIZE	528×222×415mm(1 pair)
NET WEIGHT	5 kg/pc
GROSS WEIGHT	15 kg/pair
