| Quantity: | |
|---|---|
LS205
fdB
8518220000
Description:
LS205 is a all-weather two-way speaker,fashion style,compact design,close to the ground installation,full bass,transparent and bright mid-high,grass green can be integrated with the environment,with waterproof,dustproof,windproof,anti-uv aging,the unit is specially made and treated,the cabint is formed by engineering plastic mold with three-layer of different materials composite grille the product meets the IP56 standard,to meet all-wather use. The audio transformer and band switch are designed to achieve a variety of different output powers including constant resistance.
Features:
● Pass IP56 testing
● Engineering plastic mold forming box, strong weather resistance
● 360°×90° coverage angle Applications: green squares, pedestrian walkways, parks, hotel gardens, resorts, villa courtyards
Specification:
| MODEL | LS205 |
| FREQUENCY RESPONSE(-3dB) | 70Hz-15KHz |
| FREQUENCY RESPONSE(-10dB) | 65Hz-16KHz |
| LF DRIVERS | 1×5.25"/1.5" voice coil |
| HF DRIVERS | 1×0.8"/1" voice coil |
| INPUT VOLTAGE | 100V |
| RATED POWER | 15W/30W/60W/OFF/8Ω 60W |
| SENSITIVITY(1watt/1metre) | 86dB |
| MAXIMUM SPL | 103dB continuous,109 dB peak |
| IMPEDANCE | 8 ohms |
| DISPERSION(-6dB) | 360°×90° |
| CROSSOVER FREQUENCIES | 3.2KHz |
| PACKAGE SIZE | 380×362×498mm |
| NET WEIGHT | 7.5kg/pc |
| GROSS WEIGHT | 9.5kg/pc |
Configuration:
