| Quantity: | |
|---|---|
CL4027B/CL4027W
fdB
8518220000
Description:
The CL4027 series is a 4”, two-way,all-weather column speaker with different colours or functions, with waterproof, dustproof, windproof, anti-uv aging, dustproof and waterproof covers specially designed for input and output, and multi-layer different functional grille. The product meets the IP56 standard. The exposed metal parts are sprayed with stainless steel or aluminum, and the mounting bracket is sprayed with low-carbon steel to meet all-weather use. The sound is soft and balanced. Unit configuration: 6x4" 25mm voice coil ferrite mid-bass units, 1x1" exit throat 34mm HF driver with horn, the cabinet is made of aluminum alloy, and the upper and lower panels of the cabinet are die-cast. The B and W after the model represent black, T represents the configuration of transformer and band switch to achieve a variety of different output powers including constant resistance.
Features:
● Pass IP56 testing
● Aluminum alloy housing, impact resistance, weather resistance
● Two-way design, wide horizontal and vertical angles, soft and balanced sound
● Various installation methods, easy and fast operation
●Applications: outdoor sound reinforcement, parks, churches, conference rooms, classrooms, sound reinforcement for outdoor screens
Specification:
MODEL | CL4027B/CL4027W |
FREQUENCY RESPONSE(-3db) | 125Hz-17KHz |
| FREQUENCY RESPONSE(-10db) | 120Hz-18KHz |
| LF DRIVER | 6×4",1''voice coil |
| HF DRIVER | 1×1",1.4''voice coil |
| INPUT VOLTAGE | -- |
| RATED POWER | 200W RMS 800W peak |
| SENSITIVITY(1watt/1meter) | 96dB |
| MAXIMUM SPL | 119dB continuous 125dB peak |
| IMPEDANCE | 6 ohms |
| DISPERSION(-6dB) | 100°×40° |
| CROSSOVER FREQUENCIES | 2.2kHz |
| INPUT CONNECTORS | M22-2p |
| PACKAGE SIZE(1Pair) | 1050×380×193mm |
| NET WEIGHT | 11kg/pc |
| GROSS WEIGHT | 26kg/pair |
Configuration:
Data Sheets Download:
