ES104BT/ES104WT
fdB
8518220000
Description:
The ES104BT/ES104WT is a highly weather-resistant,single 4" 2-way full range loudspeaker, the body is made of engineering plastic injection molding.fitted with one 4" mid-woofer and one 0.8" HF driver. The system conforms to IP46 international standard.ES104T is equiped with multi-tap transformer based on ES104
Features:
● Highly weather-resistant IP46 rating
● Engineering plastic injection molding
● Two kinds of mounting brackets
● Good used for meeting rooms, shops, water parks,outdoor background music, swimming pools, and a wide variety of other outdoor or indoor backgound music
Specification:
MODEL | ES104BT/ES104WT |
FREQUENCY RESPONSE(-3dB) | 75Hz-20KHz |
FREQUENCY RESPONSE(-10dB) | 70Hz-20KHz |
DRIVERS | 1×4"(100mm)/1"voice coil LF |
| 1×0.8"(20mm)/dome tweeter | |
INPUT VOLTAGE | 100V |
RATED POWER | 10W/20W/40W/OFF/16Ω 40W |
SENSITIVITY | 88dB 1watt/1 metre |
MAXIMUM SPL | 104dB continuous,110 dB peak |
IMPEDANCE | 16 ohms nominal |
DISPERSION(-6dB) | 120°×90° |
CROSSOVER FREQUENCIES | 3.5kHz passive |
INPUT CONNECTORS | covered barrier strip terminals |
PACKAGE SIZE | 412×192×271mm(1 pair) |
NET WEIGHT | 3 kg/pc |
GROSS WEIGHT | 7 kg/pair |
Configuration:
Data Sheets Download:
Description:
The ES104BT/ES104WT is a highly weather-resistant,single 4" 2-way full range loudspeaker, the body is made of engineering plastic injection molding.fitted with one 4" mid-woofer and one 0.8" HF driver. The system conforms to IP46 international standard.ES104T is equiped with multi-tap transformer based on ES104
Features:
● Highly weather-resistant IP46 rating
● Engineering plastic injection molding
● Two kinds of mounting brackets
● Good used for meeting rooms, shops, water parks,outdoor background music, swimming pools, and a wide variety of other outdoor or indoor backgound music
Specification:
MODEL | ES104BT/ES104WT |
FREQUENCY RESPONSE(-3dB) | 75Hz-20KHz |
FREQUENCY RESPONSE(-10dB) | 70Hz-20KHz |
DRIVERS | 1×4"(100mm)/1"voice coil LF |
| 1×0.8"(20mm)/dome tweeter | |
INPUT VOLTAGE | 100V |
RATED POWER | 10W/20W/40W/OFF/16Ω 40W |
SENSITIVITY | 88dB 1watt/1 metre |
MAXIMUM SPL | 104dB continuous,110 dB peak |
IMPEDANCE | 16 ohms nominal |
DISPERSION(-6dB) | 120°×90° |
CROSSOVER FREQUENCIES | 3.5kHz passive |
INPUT CONNECTORS | covered barrier strip terminals |
PACKAGE SIZE | 412×192×271mm(1 pair) |
NET WEIGHT | 3 kg/pc |
GROSS WEIGHT | 7 kg/pair |
Configuration:
Data Sheets Download:
