U218W
fdB
8518210000
Description:
U218W is a dual 18" subwoofer, bass-reflex design, sound. Unit configuration: 2x18" 100mm high efficicency woofer. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. U218WA is an active subwoofer.
Features:
●High quality unit configuration, high strength plywood housing
●Bass-reflex design, full and powerful sound
●Applications: multifunction halls, high-end hotel clubs, stadiums, touring
Specification:
MODEL | U218W |
FREQUENCY RESPONSE(-3dB) | 40Hz-250Hz |
| FREQUENCY RESPONSE(-10dB) | 35Hz-300Hz |
LF DRIVERS | 2×18"/4"voice coil |
RATED POWER | 1200W RMS,4800W peak |
SENSITIVITY(1watt/1 metre) | 103dB |
MAXIMUM SPL | 134dB continuous,140dB peak |
IMPEDANCE | 4 ohms |
INPUT CONNECTORS | 2x Speakon NL4 |
PACKAGE SIZE | 1272×872×658mm |
NET WEIGHT | 82 kg/pc |
GROSS WEIGHT | 90 kg/pair |
Configuration:
