U215VI
fdB
8518220000
Description:
The U215VI is a 15", high power, two way full range speaker with bright and powerful sound. Unit configuration: 1x15" high efficiency mid-bass unit, 1x1.4" exit throat 75mm titanium diaphragm HF driver with 90°×40° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. U215AVI is an active speaker with two channels and DSP digital amplfier.
Features:
●High quality unit configuration, high strength plywood housing
●High power
●Applications: indoor and outdoor sound reinforcement in full range, multifunction halls
Specification:
MODEL | U215VI |
FREQUENCY RESPONSE(-3dB) | 40Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 35Hz-20KHz |
LF DRIVERS | 2×15"/4"voice coil |
| HF DRIVERS | 1×2"/3"voice coil |
RATED POWER | 1200W RMS,4800W peak |
SENSITIVITY(1watt/1 metre) | 101dB |
MAXIMUM SPL | 132dB continuous,138 dB peak |
IMPEDANCE | 4 ohms |
DISPERSION(-6dB) | 90°x 50° |
CROSSOVER FREQUENCIES | 1.5kHz |
INPUT CONNECTORS | 2x Speakon NL4 |
PACKAGE SIZE | 652×592×1235mm |
NET WEIGHT | 64 kg/pc |
GROSS WEIGHT | 70 kg/PC |
Configuration:
Data Sheets Download:
