U215AVI
fdB
8518220000
Description:
The U15AVI is a classic professional speaker with the characteristics of high power,high SPL,clear and bright full-ranfe sound,rich and elastic bass,all use high quality units.The cabinet is made of multi-layer composite plywood with wear-resistant polyurea paint.
Features:
●High quality unit configuration, high strength plywood housing
●High power
●Applications: indoor and outdoor sound reinforcement in full range, multifunction halls
Specification:
MODEL | U215AVI |
FREQUENCY RESPONSE(-3dB) | 40Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 35Hz-20KHz |
LF DRIVERS | 2×15"/3"voice coil |
| HF DRIVERS | 1×2"/3"voice coil |
RATED POWER | 300W/8Ω+1200W/4Ω |
SENSITIVITY | -- |
MAXIMUM SPL | 130dB continuous,136dB peak |
IMPEDANCE | -- |
DISPERSION(-6dB) | 90°x 50° |
CROSSOVER FREQUENCIES | -- |
INPUT CONNECTORS | XLR |
PACKAGE SIZE | 650×592×1235mm |
NET WEIGHT | 55 kg/pc |
GROSS WEIGHT | 61 kg/PC |
Configuration:
