U112VI
fdB
8518220000
Description:
The U112VIis a 12" two way full range speaker with clear and bright sound. Unit configuration: 1x12" high efficiency mid-bass unit, 1x1" exit throat 44mm poliyimide diaphragm HF driver with 90°×40° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. U112DA is an active speaker with two channels and DSP digital amplfier.
Features:
●High quality unit configuration, high strength plywood housing
●Multi-hanging points and support, easy and quick operation
●Applications: large-scale indoor sound reinforcement, multifunction halls, high-end hotel clubs, touring, band reinforcement and monitor speaker
Specification:
MODEL | U112VI |
FREQUENCY RESPONSE(-3dB) | 50Hz-18kHZ |
FREQUENCY RESPONSE(-10dB) | 45Hz-20kHz |
LF DRIVERS | 1x12"/3" voice coil |
| HF DRIVERS | 1x1"/1.7 voice cioil |
RATED POWER | 300W RMS,1200W peak |
SENSITIVITY(1watt/1meter) | 97dB |
MAXIMUM SPL | 122dB continous,128dB peak |
IMPEDANCE | 8 ohms |
DISPERSION(-6dB) | 90°x40° |
CROSSOVER FREQUENCIES | 2kHz |
INPUT CONNECTORS | 2xSpeakon NL4 |
PACKAGE SIZE | 464x444x722mm |
NET WEIGHT | 21 kg/pc |
GROSS WEIGHT | 25 kg/pc |
Configuration:
