TH612DA
fdB
8518220000
Description:
TH Series is a high sensitivity, high SPL, long-throw speaker, mid-bass and HF driver all feature horn-loaded design, make the sound transparent and bright, all adopt neodymium units, the cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. The model with A is an active speaker equipped with two channels digital amplifier with DSP.
Features:
●Mid-bass and HF driver all feature horn-loaded design
●High power, high sensitivity,high SPL
● Clear,transparent and bright sound
●Can be used for single hanging, a variety of combinations of hanging
●Active or passive options are available
●Applications:theatres, concert halls, multifunction halls, lecture halls,bars, livehouse, large-scale sound reinforcement, touring
Specification:
| MODEL | TH612DA |
| FREQUENCY RESPONSE(-3dB) | 65Hz-17kHz |
| FREQUENCY RESPONSE(-10dB) | 60Hz-18kHz |
| LF DRIVERS | 2×12"Neo/3"voice coil |
| MF DRIVERS | 2×1.4"Neo/3.5"voice coil |
| HF DRIVERS | 2×1.4"Neo/1.7"voice coil |
| RATED POWER | 1500W/8Ω+460W/8Ω |
| SENSITIVITY(1watt/1meter) | -- |
| MAXIMUM SPL | 130dB continuous,136dB peak |
| IMPEDANCE | -- |
| DISPERSION(-6dB) | 80°×30° |
| CROSSOVER FREQUENCIES | -- |
| INPUT CONNECTORS | XLR |
| PACKAGE SIZE | 665×557×780mm |
| NET WEIGHT | 46 kg/pc |
| GROSS WEIGHT | 51 kg/pc |
Configuration:
Data Sheets Download:
TH612DA.pdf
