MR108A
fdB
8518220000
Description:
MR108A is a compact, small size, coaxial, 2-way full range monitor speaker, has balanced and real sound quality. Configuration:1x8" high efficency mid-bass unit and 1x1" exit throat 44mm voice coil HF driver with horn make up the coaxial. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. MR108A is equipped with digital amplifier based on MR108 to be an active speaker.
Features:
●High quality coaxial design
●Small size, light weight
●Can be placed on stage , can be hung
●Applications: Stage monitor
Specification:
| MODEL | MR108A |
| FREQUENCY RESPONSE(-3dB) | 90Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 85Hz-20kHz |
| LF DRIVERS | 1×8''/2"voice coil |
| HF DRIVERS | 1×1"/1.4"voice coil |
| RATED POWER | 300W/8Ω |
| SENSITIVITY(1watt/1 metre) | -- |
| MAXIMUM SPL | 116dB continuous,122dB peak |
| IMPEDANCE | -- |
| DISPERSION(-6dB) | 90°×90° |
| CROSSOVER FREQUENCIES | -- |
| INPUT CONNECTORS | XLR |
| PACKAGE SIZE | 420×345×425mm |
| NET WEIGHT | 12 kg/pc |
| GROSS WEIGHT | 14 kg/pc |
Data Sheets Download:
