MR108
fdB
8518220000
Description:
MR108 is a compact, small size, coaxial, 2-way full range monitor speaker, has balanced and real sound quality. Configuration:1x8" high efficency mid-bass unit and 1x1" exit throat 44mm voice coil HF driver with horn make up the coaxial. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint. MR108A is equipped with digital amplifier based on MR108 to be an active speaker.
Features:
●High quality coaxial design
●Small size, light weight
●Can be placed on stage , can be hung
●Applications: Stage monitor
Specification:
| MODEL | MR108 |
| FREQUENCY RESPONSE(-3dB) | 90Hz-18kHz |
| FREQUENCY RESPONSE(-10dB) | 85Hz-20kHz |
| LF DRIVERS | 1×8''/2"voice coil |
| HF DRIVERS | 1×1"/1.4"voice coil |
| RATED POWER | 1500W RMS,600W peak |
| SENSITIVITY(1watt/1 metre) | 95dB |
| MAXIMUM SPL | 116dB continuous,122dB peak |
| IMPEDANCE | 8 ohms |
| DISPERSION(-6dB) | 90°×90° |
| CROSSOVER FREQUENCIES | 2.2kHz |
| INPUT CONNECTORS | 2×Speakon NL4 |
| PACKAGE SIZE | 420×345×425mm |
| NET WEIGHT | 10 kg/pc |
| GROSS WEIGHT | 12 kg/pc |
Configuration:
