LH12Ⅱ
fdB
8518220000
Description:
The LH12Ⅱ is a 12", light weight, high SPL, two way full range speaker with clear and bright sound. Unit configuration: 1x12" high efficiency neodymium mid-bass unit, 1x1" exit throat 44mm neodymium poliyimide diaphragm HF driver with 90°×40° rotatable horn. The cabinet is made of multilayer composite plywood with wear-resistant polyurea paint
Features:
●High quality unit configuration, high strength plywood housing
●Small size, light weight, easy handling and fixed installation
●Multi-hanging points and support, easy and quick operation
●Applications: large-scale indoor sound reinforcement, multifunction halls, high- end hotel clubs, touring, band reinforcement and monitor speaker
Specification:
MODEL | LH12Ⅱ |
FREQUENCY RESPONSE(-3dB) | 55Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 50Hz-20KHz |
LF DRIVERS | 1×12"Neo/3"voice coil |
| HF DRIVERS | 1×1"Neo/1.7"voice coil |
| RATED POWER | 300W RMS,1200W peak |
SENSITIVITY(1watt/1 metre) | 97dB |
MAXIMUM SPL | 122dB continuous,128 dB peak |
IMPEDANCE | 8 ohms |
DISPERSION(-6dB) | 90°×40° |
CROSSOVER FREQUENCIES | 2.5kHz |
INPUT CONNECTORS | 2xSpeakon NL4 |
PACKAGE SIZE | 464×444×750mm |
NET WEIGHT | 17 kg/pc |
GROSS WEIGHT | 19 kg/pc |
Configuration:
