LH10Ⅱ
fdB
8518220000
Description:
The LH10Ⅱ is an all-purpose 2-way full-range loudspeaker designed for near-field contracting applications.Fitted with one 10" neodymium woofer and one 1" exit neodymium compression driver coupled to a rotatable horn.
Features:
●High quality plywood with special environmental protection paint
●Rotatable 90°×50° horn
●Flexible mounting options
●Top hat fitting for tripod
●Light weight, convenient to move and fix installation
●Used for moving performance, multi-purpose hall,conference room,hotel, KTV and band
Specification:
MODEL | LH10Ⅱ |
FREQUENCY RESPONSE(-3dB) | 60Hz-18KHz |
FREQUENCY RESPONSE(-10dB) | 55Hz-20KHz |
LF DRIVERS | 1×10"Neo/3"voice coil |
| HF DRIVERS | 1×1"Neo/1.7"voice coil |
| RATED POWER | 250W RMS,1000W peak |
SENSITIVITY(1watt/1 metre) | 96dB |
MAXIMUM SPL | 120dB continuous,126 dB peak |
IMPEDANCE | 8 ohms |
DISPERSION(-6dB) | 90°×50° |
CROSSOVER FREQUENCIES | 2.5kHz |
INPUT CONNECTORS | 2xSpeakon NL4 |
PACKAGE SIZE | 388×376×600mm |
NET WEIGHT | 13 kg/pc |
GROSS WEIGHT | 14 kg/pc |
Configuration:
